General
- TypeDesktop
- Functionoptional: fax, scan, print, Copy
- Print technologyLaser b/w
- Original formatmax A3 from platen glass
- Print speed (A4, Simplex) B/W40 b/w-pages/min.
- Copy speed (A4, Simplex) B/W40 b/w-pages/min.
- Print speed (A4, Duplex) B/W21 b/w-pages/min.
- Copy speed (A4, Duplex) B/W21 b/w-pages/min.
- 1st page (printing, colour)undefined seconds
- 1st page (printing, b/w)4.2 seconds
- 1st page (copying, colour)undefined seconds
- 1st page (copying, b/w)3.6 seconds
- Warm-up time18 seconds
- Copy resolution600 x 600 dpi
- Greyscales256
- Paper feed (Universal cassettes amount)2 x 500 sheet universal cassettes
- Paper feed (1st cassette types)A5R-A3
- Paper feed (2nd cassette types)A5R-A3
- Paper feed (Multi-Bypass amount)100 sheet multi-bypass (A6R-A3)
- Paper feed (Multi-Bypass types)A6R-A3
- Paper weights (Universal cassette min)60 g/m²
- Paper weights (Universal cassette max)163 g/m²
- Paper weights (Multi-Bypass min)45 g/m²
- Paper weights (Multi-Bypass max)256 g/m²
- Paper weights (Duplex min)60 g/m²
- Paper weights (Duplex max)163 g/m²
- Job Separator50 sheet A4 (standard)
- System memory (RAM)4 GB
- System memory (RAM max)4 GB
- System memory (SSD)32 GB
- Continuous copying (min)1
- Continuous copying (max)9999
- Zoom (min)25 %
- Zoom (max)400 %
- Zoom (step)1 %
- FunctionsAdjustable colour touch screen (10.1 inch), 1000 management codes, skip blank pages, encryption/overwriting of hard disk data (Data Security Kit and Trusted Platform Module), secure boot and run time integrity check, trusted platform modul (TPM), duplex, etc.
Dimensions / Weight
- Dimensions (height)683 mm
- Dimensions (width)594 mm
- Dimensions (depth)696 mm
- Weight59 kg
Environment
- Mains voltage220/240 V
- Utility frequency50/60 Hz
- Power consumption (max)1620 W
- Power consumption (busy)600 W
- Power consumption (standby)100 W
- Power consumption (sleep)0.5 W
- Power consumption (TEC)0.53 kwh/week
- Noise level (busy, b/w)49 dB(A)
- Noise level (standby)31.3 dB(A)
- SafetyCE, GS/TÜV
Printing system
- TypeIntegrated within the system
- Print formatA6R-A3
- Print resolution (min)600 x 600 dpi
- Print resolution (max)1,200 x 1,200 dpi
- Interfaces10/100/1000BaseTX, USB host, USB 3.0, SD-Card Slot
- Network protocolsTCP/IP, Net BEUI
- Operating systemsWindows 8.1, Windows 10, Server 2012 R2, Server 2016, Server 2019, Linux, Mac ex OS 10.9
- EmulationsKPDL 3 (PostScript 3 compatible), XPS, PRESCRIBE Ile, PCL6 (PCL 5c, XL), PDF
- FunctionsUSB direct printing, Apple AirPrint, NFC, private printing, barcode printing, SNMPv3, PDF direct printing, Wi-Fi, etc.
Scanning system
- Scan typeCCD colour and b/w
- Scan formatmax A3
- Scan speed (Feeder 2, simplex, b/w)undefined DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 2, duplex, colour)undefined DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 2, duplex, b/w)1 DIN-A4-image pages/min. in 300 dpi
- Scan resolution300 dpi, 200 dpi, 400 dpi, 600 dpi
- Scan modePhoto, text, photo/text, optimised for OCR
- File typesTIFF, JPEG, XPS, PDF/A, PDF/A-1a, PDF/A-1b, PDF/A-2a, PDF/A-2b, high compression and encrypted PDF, OpenXPS
- Interfaces10/100/1000BaseTX
- Network protocolTCP/IP
- Operating systemsWindows 10, Server 2012 R2, Server 2016, Windows 8.1, Server 2019
- Functionsscan to FTP, Scan to SMB, SMTP authentication, WIA scan, TWAIN scan, scan to USB, scan to e-mail
Fax system
- TypeFaxsystem 12
- CompatibilitySuper G3
- Original formatmax A3
- Modem speed33.6 kbps
- Transmission speed3 seconds or less using JBIG
- Compression methodJBIG, MMR, MH, MR
- Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi), 600 x 600 dpi
- Fax memory170 MB
- Abbreviated dial2000 numbers
- One touch dial1000 numbers
- Group dial500 numbers
- Operating systemsWindows 8.1, Windows 10, Server 2012 R2, Server 2016, Server 2019
- Functionsdelayed transmission, max 2 fax kits for parallel transmission and reception, automatic redialling, Network fax driver
Options
- Original feederDP-7140 document processor with automatic reverse function (A5R-A3, capacity: 50 sheet A4, paper weight 45-160 g/m²), DP-7150 document processor with automatic reverse function (A6R-A3, capacity: 140 sheet A4, paper weight 35- 160 g/m²), DP-7170 document processor with simultaneous duplex scanning and multi-feed detection (A6R-A3, capacity: 320 sheet A4, paper weight 35-220 g/m²), DP-7160 document processor with simultaneous duplex scanning (A6R-A4, capacity: 320 sheet A4, paper weight 35-220 g/m²)
- Original platen coverPlaten cover type E (if document processor is not installed)
- FinisherDF-7120 (capacity: 1,000 sheet A4, stapling max 50 sheet A4),, DF-791 (capacity: 3,000 sheet A4, stapling max 65 sheet A4), PH-7C hole punch unit for DF-7120/DF-791
- Paper feedPF-810 (2 x 1,500 sheet large capacity cassette [A4]), PF-791 (2 x 500 sheet universal cassettes [A5R-A3])
- Other optionsScan extension kit (A), Card authentication kit (B), HD-15 (320 GB HDD), HD-16 (1 TB HDD), NK-7120 Numeric Keyboard (10 keys), Keyboard holder 10, Internet fax kit (A), IB-50 Gigabit Ethernet card, IB-51 WLAN card (IEEE802.11/b/g/n), IB-37 WLAN card (IEEE802.11a/b/g/n/ac), cabinet no. 70, Banner guide (A), DT-730(B) Document tray, UG-34 Emulation option kit, UG-33 ThinPrint® kit
