General
- TypeDesktop
- FunctionCopy, print, scan, fax
- Print technologyLaser colour and b/w
- Original formatmax A4 from platen glass
- Original feeder100 sheet A4 (dual-scan document processor), A6R-A4, 50-120 g/m² (simplex/duplex), banner: max 915 mm length, A4 width
- Print speed (A4, Simplex) B/W35 b/w-pages/min.
- Copy speed (A4, Simplex) B/W35 b/w-pages/min.
- Print speed (A4, Duplex) B/W17 b/w-pages/min.
- Copy speed (A4, Duplex) B/W17 b/w-pages/min.
- Print speed (A4, Simplex) Colour35 colour pages/min
- Copy speed (A4, Simplex) Colour35 colour pages/min
- Print speed (A4, Duplex) Colour17 colour pages/min
- Copy speed (A4, Duplex) Colour17 colour pages/min
- 1st page (printing, colour)7.5 seconds
- 1st page (printing, b/w)6 seconds
- 1st page (copying, colour)8.5 seconds
- 1st page (copying, b/w)7.5 seconds
- Warm-up time25 seconds
- Copy resolution600 x 600 dpi
- Greyscales256
- Paper feed (Universal cassettes amount)1 x 250 sheet
- Paper feed (1st cassette types)A6R-A4
- Paper feed (Multi-Bypass amount)100 sheet multi-bypass (A6R-A3)
- Paper feed (Multi-Bypass types)A6R-A4 [min 70 x 148 mm, max 216 x 356 mm]
- Paper weights (Universal cassette min)60 g/m²
- Paper weights (Universal cassette max)163 g/m²
- Paper weights (Multi-Bypass min)60 g/m²
- Paper weights (Multi-Bypass max)220 g/m²
- Paper weights (Duplex min)60 g/m²
- Paper weights (Duplex max)163 g/m²
- Paper output250 sheet A4
- System memory (RAM)1 GB
- System memory (RAM max)3 GB
- System memory (Optional)32/128 GB SSD
- Continuous copying (min)1
- Continuous copying (max)999
- Zoom (min)25 %
- Zoom (max)400 %
- Zoom (step)1 %
- FunctionsAdjustable colour touch screen (7 inch), duplex, job reservation, job programs, ID card copy, continuous scan, skip blank pages, N-up, quiet mode (half speed mode), login by function, 100 management codes
Dimensions / Weight
Environment
- Mains voltage220/240 V
- Utility frequency50/60 Hz
- Power consumption (max)1346 W
- Power consumption (busy)521 W
- Power consumption (standby)84 W
- Power consumption (sleep)0.6 W
- Power consumption (TEC)0.49 kwh/week
- Noise level (busy, b/w)50.3 dB(A)
- Noise level (busy, colour)50.4 dB(A)
- Noise level (standby)29.6 dB(A)
- SafetyGS/TÜV, CE
Printing system
- TypeIntegrated within the system
- Print formatA6R-A4
- Print resolution (min)600 x 600 dpi
- Print resolution (max)1,200 x 1,200 dpi (reduced speed)
- ProcessorARM Cortex-A9 Dual core 1.2 GHz , ARM Cortex-M3 100 MHz
- InterfacesUSB 2.0, 10/100/1000BaseTX, USB host (2), Wi-Fi
- Network protocolsTCP/IP, Net BEUI
- Operating systemsWindows 7, Windows 8, Windows 8.1, Windows 10, Server 2008 R2, Server 2012 R2, Server 2016, Server 2019, Novell NetWare, Linux, Mac ex OS 10.8
- EmulationsPCL6 (PCL 5c, XL), KPDL 3 (PostScript 3 compatible), PRESCRIBE Ilc, PDF 1.7, XPS
- Functions200 dpi, USB direct printing, PDF direct printing, printing of e-mails, private printing, barcode printing, quiet mode (half speed mode), Mobile Print (Android/iOS), Apple AirPrint, Google Cloud Print, Wi-Fi
Scanning system
- Scan typeCCD colour and b/w
- Scan formatmax A4
- Scan speed (Feeder 1, simplex, colour)40 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, b/w)60 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, colour)46 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, b/w)62 DIN-A4-image pages/min. in 300 dpi
- Scan resolution200 dpi, 300 dpi, 400 dpi, 600 dpi
- Scan modePhoto, text, photo/text, optimised for OCR
- File typesTIFF, JPEG, PDF, PDF/A-1, PDF/A-2, high compression PDF, encrypted PDF, XPS, OpenXPS, MS Office/text-searchable PDF
- Interfaces10/100/1000BaseTX, USB 2.0
- Network protocolTCP/IP
- Operating systemsWindows 7, Windows 8, Windows 8.1, Windows 10, Server 2003, Server 2008 R2, Server 2012 R2, Server 2016, Server 2019
- FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
Fax system
- TypeIntegrated within the system
- CompatibilitySuper G3
- Original formatmax A4
- Modem speed33.6 kbps
- Transmission speed3 seconds or less using JBIG
- Compression methodJBIG, MMR, MR, MH
- Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi)
- Fax memory8 MB
- Fax memory (image)3.5 MB
- Abbreviated dial200 numbers
- One touch dial100 numbers
- Group dial50 numbers
- Operating systemsWindows 7, Windows 8, Windows 8.1, Server 2008 R2, Server 2012 R2, Server 2016, Server 2019
- FunctionsNetwork fax driver, automatic redialling, delayed transmission
Options
- FinisherMS-5100 manual stapler for 20 sheet
- Paper feedmax 3 x PF-5100 (500 sheet universal cassettes [A5R-A4, 60-220 g/m²])
- Other optionsData security kit (E), Scan extension kit (A), Card authentication kit (B), Card reader holder (10), UG-33 ThinPrint® kit, IB-50 Gigabit Ethernet card, IB-36 or IB-51 WLAN card, HD-6 SSD (32 GB), HD-7 SSD (128 GB), cabinet no. 72 (high), cabinet no. 73 (low)
